Spare parts and accessories for YAMAHA XT 600 Z - 3AJ

3AJ-000101 - 3AJ-056101

My Bike
XT 600 Z
1988 - 1991
Find another bike
Specifications *
Engine size:
595
Cylinders:
1
hp/kW:
46/34
Vehicle weight (kg):
185
Seat height (mm):
890
Valve clearance (intake):
KALT 0,07-0,12 MM
Valve clearance (exhaust):
KALT 0,12-0,17 MM
Engine idle speed:
1250-1350 U/MIN
Carburettor air screw:
2,5 AUSDREHUNGEN
Tyre pressure (front):
1,5 (1,8) BAR
Tyre pressure (rear):
2,2 (2,5) BAR
Spark plug 1:
NGK DPR7EA-9
Spark plug 2:
NGK DPR7EIX-9
Electrode gap:
0,9 MM
Fork tube diam.:
40 MM TELEGABEL
Front/rear sprockets:
15/40/104 (BJ.88)
Chain/Final drive:
15/45/106 (BJ.89-)
Capacities *
Fork oil per rod:
537 ML SAE 10W
Engine oil w/o filter:
1,9 L SAE 20W-40
Engine oil with filter:
2,0 LITER
Brake fluid:
DOT 4
Fuel:
23,0 LITER
Coolant:
LUFTGEKÜHLT
* We acquire the data with care, but without any guarantee
Louis has taken great care in compiling the specifications and associated products. They apply to the model of the selected vehicle that is sold in Germany. The specifications of models sold in other countries may differ. Louis does not accept any responsibility for the accuracy of the information provided. Prior to installation, you should consult your motorcycle's handbook and/or seek information from the manufacturer.
